I’ve just open sourced a library called ping-play which brings BigPipe streaming to the Play Framework. It includes tools for a) splitting your pages up into small “pagelets”, which makes it easier to maintain large websites, and b) streaming those pagelets down to the browser as soon as they are ready, which can significantly reduce page load time.

Check out ping-play on GitHub now!

In this blog post, I’ll describe what BigPipe streaming is all about, how to add BigPipe streaming to your Play apps, and where to get more info.

What is BigPipe?

In a typical web app, before you can render a page, you have to make requests to multiple remote backend services to fetch data (e.g. RESTful HTTP calls to a profile service, a search service, an ads service, etc). You then have to wait for all of these remote calls to come back before you can send any data back to the browser. For example, the following screen capture shows a page that makes 6 remote service calls, most of which complete in few hundred milliseconds, but one takes over 5 seconds. As a result, the time to first byte is 5 seconds, during which the user sees a completely blank page:

A page without BigPipe. It takes a long time before the user sees anything.
A page without BigPipe. It takes a long time before the user sees anything.

With BigPipe, you can start streaming data back to the browser without waiting for the backends at all, and fill in the page incrementally as each backend responds. For example, the following screen capture shows the same page making the same 6 remote service calls, but this time rendered using BigPipe. The header and much of the markup is sent back instantly, so time to first byte is 10 milliseconds (instead of 5 seconds), static content (i.e. CSS, JS, images) can start loading right away, and then, as each backend service responds, the corresponding part of the page (i.e. the pagelet) is sent to the browser and rendered on the screen:

A page with BigPipe. The user sees the page instantly.
A page with BigPipe. The user sees the page instantly.

How to use ping-play

To understand how to transform your Play app to use BigPipe, it’s helpful to first see an example that does not use BigPipe (note, the example is in Scala, but ping-play supports Java too!). Here is the controller code for the example mentioned above:

class WithoutBigPipe(client: FakeServiceClient) extends Controller {
  def index = Action.async { implicit request =>
    // Make several fake service calls in parallel to represent
    // fetching data from remote backends. Some of the calls will
    // be fast, some medium, and some slow.
    val profileFuture = client.fakeRemoteCallMedium("profile")
    val graphFuture = client.fakeRemoteCallMedium("graph")
    val feedFuture = client.fakeRemoteCallSlow("feed")
    val inboxFuture = client.fakeRemoteCallSlow("inbox")
    val adsFuture = client.fakeRemoteCallFast("ads")
    val searchFuture = client.fakeRemoteCallFast("search")

    // Wait for all the remote calls to complete
    for {
      profile <- profileFuture
      graph <- graphFuture
      feed <- feedFuture
      inbox <- inboxFuture
      ads <- adsFuture
      search <- searchFuture
    } yield {
      // Render the template once all the data is available
      Ok(views.html.withoutBigPipe(
        profile, graph, feed, inbox, ads, search))
    }
  }
}

This controller makes 6 remote service calls, gets back 6 Future objects, and when they have all redeemed, it uses them to render the following template:

@(profile: data.Response, graph: data.Response, feed: data.Response,
  inbox: data.Response, ads: data.Response, search: data.Response)

<html>
  <head>
    <link rel="stylesheet" href="/assets/stylesheets/main.css">
  </head>
  <body>
    <h1>Without Big Pipe</h1>
    <table class="wrapper">
      <tr>
        <td><div id="profile">@views.html.helpers.module(profile)</div></td>
        <td><div id="ads">@views.html.helpers.module(ads)</div></td>
        <td><div id="feed">@views.html.helpers.module(feed)</div></td>
      </tr>
      <tr>
        <td><div id="search">@views.html.helpers.module(search)</div></td>
        <td><div id="inbox">@views.html.helpers.module(inbox)</div></td>
        <td><div id="graph">@views.html.helpers.module(graph)</div></td>
      </tr>
    </table>
  </body>
</html>

When you load this page, nothing will show up on the screen until all of the backend calls complete, which will take about 5 seconds.

To transform this page to use BigPipe, you first add the big-pipe dependency to your build (note, ping-play requires Play 2.4, Scala 2.11.6, SBT 0.13.8, and Java 8):

libraryDependencies += "com.ybrikman.ping" %% "big-pipe" % "0.0.12"

Next, add support for the .scala.stream template type and some imports for it to your build:

TwirlKeys.templateFormats ++=
  Map("stream" -> "com.ybrikman.ping.scalaapi.bigpipe.HtmlStreamFormat"),
TwirlKeys.templateImports ++=
  Vector("com.ybrikman.ping.scalaapi.bigpipe.HtmlStream",
         "com.ybrikman.ping.scalaapi.bigpipe._")

Now you can create streaming templates. These templates can mix normal HTML markup, which will be streamed to the browser immediately, with the HtmlStream class, which is a wrapper for an Enumerator[Html] that will be streamed to the browser whenever the Enumerator has data. Here is is the streaming version of the template above:

@(bigPipe: BigPipe, profile: Pagelet, graph: Pagelet, feed: Pagelet,
  inbox: Pagelet, ads: Pagelet, search: Pagelet)

<html>
  <head>
    <link rel="stylesheet" href="/assets/stylesheets/main.css">
    <!-- Include the BigPipe JavaScript at the top of the page -->
    <script src="/assets/com/ybrikman/ping/big-pipe.js"></script>
  </head>
  <body>
    <h1>With Big Pipe</h1>
    @HtmlStream.fromHtml(views.html.helpers.timing())

    <!--
      Wrap the entire body of your page with a bigPipe.render call.
      The pagelets parameter contains a Map from Pagelet id to the
      HtmlStream for that Pagelet. You should put the HtmlStream
      for each of your Pagelets into the appropriate place in the
      markup.
    -->
    @bigPipe.render { pagelets =>
      <table class="wrapper">
        <tr>
          <td>@pagelets(profile.id)</td>
          <td>@pagelets(ads.id)</td>
          <td>@pagelets(feed.id)</td>
        </tr>
        <tr>
          <td>@pagelets(search.id)</td>
          <td>@pagelets(inbox.id)</td>
          <td>@pagelets(graph.id)</td>
        </tr>
      </table>
    }

    </body>
</html>

The key changes to notice from the original template are:

  1. Most of the markup in the page is wrapped in a call to the BigPipe.render method.
  2. The BigPipe.render method gives you a parameter, named pagelets in the example above, that is a Map from Pagelet id to the HtmlStream for that Pagelet. The idea is to place the HtmlStream for each of your Pagelets into the proper place in the markup where that Pagelet should appear.
  3. You need to include big-pipe.js in the head of the document.
class WithBigPipe(client: FakeServiceClient) extends Controller {

  def index = Action {
    // Make several fake service calls in parallel to represent
    // fetching data from remote backends. Some of the calls will
    // be fast, some medium, and some slow.
    val profileFuture = client.fakeRemoteCallMedium("profile")
    val graphFuture = client.fakeRemoteCallMedium("graph")
    val feedFuture = client.fakeRemoteCallSlow("feed")
    val inboxFuture = client.fakeRemoteCallSlow("inbox")
    val adsFuture = client.fakeRemoteCallFast("ads")
    val searchFuture = client.fakeRemoteCallFast("search")

    // Convert each Future into a Pagelet
    val profile = pagelet("profile", profileFuture)
    val graph = pagelet("graph", graphFuture)
    val feed = pagelet("feed", feedFuture)
    val inbox = pagelet("inbox", inboxFuture)
    val ads = pagelet("ads", adsFuture)
    val search = pagelet("search", searchFuture)

    // Use BigPipe to compose the pagelets and render
    // them immediately using a streaming template
    val bigPipe = new BigPipe(
      PageletRenderOptions.ClientSide,
      profile, graph, feed, inbox, ads, search)
    Ok.chunked(views.stream.withBigPipe(bigPipe,
      profile, graph, feed, inbox, ads, search))
  }
}

The key changes to notice from the original controller are:

  1. Instead of waiting for all of the service calls to redeem, you render each one individually into Html as soon as the data is available, giving you a Future[Html].
  2. Each Future[Html], plus the DOM id of where in the DOM it should be inserted, is wrapped in an HtmlPagelet object.
  3. The HtmlPagelet objects are composed into a BigPipe object, and told to use client-side rendering.
  4. This BigPipe instance and all the HtmlPagelet objects are passed to the streaming template for rendering.

When you load this page, you will see the outline of the page almost immediately, and each pagelet will fill in this outline as soon as the corresponding remote service responds.

More info

The ping-play project started as the sample app for one of my talks (you can find the slides here):

I only recently had a chance to turn the code in the sample app into a reusable library, complete with tests and documentation. It’s still in the alpha stage, but I’d love to get your feedback, bug reports, and pull requests in the ping-play GitHub repo. And if you end up using ping-play in production, I’d love to hear about your experiences, so send me an email!
